Protocol for Setting Up OpenVPN on Raspberry Pi Using PiVPN

This guide will walk you through installing and configuring OpenVPN on a Raspberry Pi using PiVPN.

---

1. Prerequisites

• Raspberry Pi (Raspberry Pi 3, 4, or 5 recommended)
• Raspberry Pi OS (Lite or Full version)
• Internet connection
• SSH access or direct terminal access
• Static IP or Dynamic DNS (DDNS) for external access

---

2. Update and Upgrade System

Before installing OpenVPN, update the system:

sudo apt update && sudo apt upgrade -y

---

3. Install PiVPN

Run the PiVPN installation script:

curl -L https://install.pivpn.io | bash

This launches an interactive installer.

---

4. Configure OpenVPN

During installation, follow these steps:

1. Select OpenVPN when prompted.


2. Set Static IP Address
   • The installer will ask if you want to set a static IP.
   • Accept the default or manually configure one.


3. Select UDP or TCP
   • UDP (default, recommended) for better performance.
   • TCP for firewall bypassing but slower speed.


4. Choose Port (Default: 1194)
   • You can change it if needed.


5. Choose Encryption Settings
   • Select RSA key size (default: 2048-bit or 4096-bit for stronger security).


6. Select DNS Provider
   • Choose from OpenDNS, Google, Cloudflare, or a custom DNS.


7. Confirm Installation
   • The script will install and configure OpenVPN.

---

5. Create a VPN User Profile

After installation, create a VPN user profile:

pivpn add

Follow the prompts to:

• Enter a username.
• Set a password (if required).

This will generate a .ovpn configuration file stored in /home/pi/configs/.

---

6. Configure Port Forwarding

To access the VPN from outside your network:

1. Log in to your router’s admin panel.
2. Locate Port Forwarding settings.
3. Forward UDP Port 1194 to your Raspberry Pi’s local IP address.
4. Save and restart your router.

---

7. Transfer the VPN Configuration File

To connect to your VPN, transfer the .ovpn file to your client device:

• Use SCP, SFTP, or a USB drive to move the file.
• Example command for SCP:

  scp pi@your_rpi_ip:/home/pi/configs/client.ovpn ~/Downloads/


• Alternatively, use an SFTP client like WinSCP or FileZilla.

---

8. Connect to OpenVPN

• PC (Windows/macOS/Linux):

  1. Install the OpenVPN client from openvpn.net.
  2. Import the .ovpn file.
  3. Click Connect.

• Android/iOS:

  1. Install OpenVPN Connect from the App Store or Google Play.
  2. Import the .ovpn file.
  3. Connect to your VPN.

---

9. (Optional) Set Up Dynamic DNS (DDNS)

If your public IP changes frequently, use DDNS:

• Sign up for a free No-IP or DuckDNS account.
• Configure DDNS on your router or install a DDNS client on the Raspberry Pi.

Example (for No-IP):

sudo apt install ddclient
sudo nano /etc/ddclient.conf

Add your No-IP credentials and domain.

---

10. Test the VPN

• Connect from an external network (e.g., mobile data).
• Visit whatismyipaddress.com to check if your public IP matches your VPN server.

---

That's it! 🎉 Your OpenVPN server on Raspberry Pi is now set up.

Let me know if you need further assistance! 🚀
